Instrumentation /MO200 SYSTEM
30
System Function:
Automatic, discrete, random access, Bench-top, STAT
sample priority.
Throughput: Constant 200 tests/hour, up to 330 tests/
hour with ISE.
Measuringprinciples: Absorbance photometry,
Turbidimetry, Ion Selective Electrode technology.
Methodology: End-point, Fixed-time, Kinetic, optional
ISE single/dual reagent chemistries, monochromatic /
bi-chromatic.
Open systemwith user defined profiles and calculation.
Reagent/Sample Handling:
Reagent/Sample tray: 40 positions for reagents and 40
positions for samples in 24-hour refrigerated compartment
(2~12 ºC).
Reagent volume: R1: 10~350μl, step by 1μl;
R2: 10~200μl, step by 1μl.
Sample volume: 2~45μl, step by 0.1μl. Primary tubes
and different sample cups.
Reagent/Sample probe: Liquid level detection, vertical
& horizontal collision protection and inventory checking,
reagent pre-warming.
Probe cleaning: Automatic washing for interior and
exterior. Carry over <0.1%.
Automatic sample dilution: Pre-dilution and post-
dilution.
External Bar Code Reader (optional).
ISE Module (optional).
Measuring K+, Na+, Cl-, Li+.
Reaction System:
Reaction rotor: Rotating tray, containing 80 cuvettes.
Cuvette: Reusable, optical length 5mm .
Reaction volume: 150~500μl.
Operating temperature: 37± 0.1 ºC.
MixingUnit: Independent mixing bar.
Optical System:
Light Source: Halogen-tungsten lamp.
Photometer: Reversed, grating optical system.
Wavelength: 12wavelengths, 340nm, 380nm, 412nm,
450nm, 505nm, 546nm, 570nm, 605nm, 660nm, 700nm,
740nm, 800nm.
Absorption range: 0~3.3Abs (10mm conversion), resolution
0.0001Abs.
Control and Calibration:
Calibrationmode: Linear (one point, two points and
multi-points), Logit-Log 4P, Logit-Log 5P, spline, exponential,
polynomial, parabola.
Control rules: X-R, L-J,Westgardmulti-rule, Cumulative sum
check, twin plot.
Operation Unit:
Operation system:Windows 7.
Interface: RS-232.
Working Conditions:
Power Supply: 200~240V, 50/60Hz, ≤1500W or
100~130V, 50/60Hz, ≤1500W.
Temperature: 15-30 ºC for operation.
Humidity: 35-85% RH.
Dimensions: 860mm(W)×700mm(D)×625mm.
Weight: 130 kg.
